CGDI CG100X New Generation Programmer for Airbag Reset Mileage Adjustment and Chip Reading

CG100X programmer covers 90% of the car models and modules in the market, including American, German, French, European, Korean, Japanese, Italian, Chinese domestic series, as well as engineering vehicles and motorcycles. It is powerful, and is the first choice for your store.

Functions

1. Meter mileage adjustment

The software is embedded with intelligent algorithms, and the mileage data is automatically analyzed. It supports more than 4,600 car models, with a success rate of over 95%. It is closely following the market and is being upgraded in real time.

2. Airbag computer reset

Contains more than 4,500 ACU models, dedicated to solving airbag faults, analyzing the cause of the light, perfectly clearing the fault code, giving car owners peace of mind, and more models are continuously added.

3. Car body failure maintenance

Focus on automotive electronic faults, good at repairing various common faults, support engine computer, steering angle, footwell module, keyless entry module, audio amplifier, gearbox computer, 48V light hybrid lithium battery, 12V lithium battery, etc. A body computer that provides vehicle data and assists repairmen in resolving vehicle failures.

4. Accessory clone replacement

Solve the pain points of the repair shop, a single device can replace accessories, data cloning, analysis and repair, one-click operation without asking for help.

5. Chip Data Burning

Covers more than 90% of automotive chips, supports more than 1,800 models, reads, modifies, writes, erases, partitions and saves to meet daily car repair needs, and can also use the browser that comes with the software to analyze data.

Octal Chip (EEPROM):

24 series, 25 series, 35 series, 93 series, 95 series, X50 series, S29 series, RH series, CAT10 series, CR series

For Fujitsu

MB90 series, MB91 series, MB96 series

For Microchip

PIC18F series

For Texas Instruments (TI)

TMS series

NXP (NXP)

S32K1 series

ForMotorola/Freescale

9S08 series, 9S12 series, HC908 series, HC912 series, MAC series, MPC56 series

Atmel

ForATMEGA series

ForRenesas

H8SX series, M32R series, R5F10D series, RH850 series, V850 series

Infineon

TC series, XC series

Saiyi Law (ST)

SPC series, ST10F series, STM32F series, STM8 series

Cypress/Spansion Semiconductor (Cypress/Spansion)

S6J series

6. Car key matching

Support BMW CAS series and Land Rover models, automatically display the key ID and usage status, and assist the locksmith to complete the key matching work.

Features:

1. Top ten accessories, functional classification

In addition to the main unit, it comes with 10 kinds of accessories, and the functions do not overlap; the DB25 connection method is used, which is more stable and safe; the wire number is clearly marked to avoid welding errors.

2. Reading and writing speed up, status monitoring

Compared with conventional programmers on the market, CG100X has an overall speedup of more than 120% for chip reading and writing, and some chips can reach 200%. The operation is monitored in real time to protect data and chips. For large-capacity eight-pin chips, the speed of reading and writing is increased by more than 500%, shortening the operation time, so that customers no longer have to wait, and truly achieve twice the result with half the effort.

3. Eight pins without dismantling, pin detection

Supports eight-pin chips without dismantling, avoiding the risk of back and forth soldering. Strong drive capability, free from communication interference. Provide pin detection, red means poor contact, green means good contact, visually display the pin status. It is more compatible with Honda instruments without dismantling, and provides wiring diagrams to avoid motor damage caused by disassembling the pointer. More disassembly-free

wiring diagrams are continuously added.

4. Intelligent algorithm, real-time upgrade

Automatic analysis of instrument kilometers, the error does not exceed 32Km, some hybrid models support modification of HEV+EV, engineering vehicles can modify working hours, and more than 50% of trucks provide fuel consumption modification.

Airbag Computer Reset Provides Two Solutions: Fault Clearing and Data Overwriting.

Fault clearing:

The original data is stored in the chip, and the fault code is clear, such as collision fault or air curtain fault. If you choose this repair method, only the relevant fault data in the chip will be cleared, and other data areas will not be
affected.

Data Coverage: When we are not sure how many jobs we have received and the data is not the most original, we can choose this repair method. After replacing all the data in the chip, a fault code may be reported due to the different configuration of the vehicle, and we need to reprogram and match. Focus on the development of R7F7 instrument, D70F instrument, SPC instrument and new airbag computer, so that 100% of the eight-pin chip can be disassembled, and is committed to covering 99% of the models and modules in the market.

5. Hardware upgrade, data loss prevention

Although CG100X and CG100 are different in one word, the equipment is completely different. CG100X adopts the industry's ideal architecture design and is equipped with the world's most advanced MCU. It is known as a fighter among single-chip computers, and its operation is more stable and safer. The advantages in hardware come from market demand. We attach great importance to customer feedback and suggestions. CG100X will support new modules and new chips more easily.

Adopting DB25 communication interface, compact design, stronger driving ability, OBD mode can be upgraded later, and supports CAN, LIN, K and other automotive communication protocols.

6. Easy access, automatic search

1. Open the software without plugging in the device, which is convenient for viewing the vehicle model and functions;

2. The car model search automatically matches special characters such as spaces and bars, regardless of case;

3. The general programmer search mask directly displays the chip;

4. In the list interface, click to enter and press Enter to enter;

5. Support picture scaling, display file open/save path.

Update Information:

V1.1.2.0 NEW(2023.04.24):

The following car models are added for car mileage adjustment:

For Volkswagen MQB D70F3526(A2C81589700) (reading and writing)

For Volkswagen MQB D70F3529 (read and write)

For Volkswagen MQB D70F3532(A2C81589500) (reading and writing)

For Buick GL8 D70F3558(BCM) (read and write)

Comparison

Package Includes:

1pc x CG100X unit

1pc x EEPROM holder

1pc x EEPROM adapter

1pc x PRO cable

1pc x USB cable

1pc x CAN cable

1pc x EEPROM solering cable

1pc x EEPROM clip

1pc x adapter

1pc x EEPROM adapter
